Details

Size	Working pressure		Flow Rate	Burst Pressures
			@0,2 MPa pressure drop
mm	inch	MPa (PSI)	I/min(GPM)	MPa(PSI)	MPa(PSI)	MPa(PSI)
6.3	1/4″	60(8700)	12(3.18)	60(8700)	60(8700)	150(21750)
10	3/8″	55(7975)	23(6.10)	55(7975)	55(7975)	140(20300)
12.5	1/2″	55(7975)	45(11.93)	55(7975)	55(7975)	140(20300)
20	3/4″	55(7975)	74(19.61)	55(7975)	55(7975)	140(20300)
25	1″	50(7250)	100(26.50)	50(7250)	50(7250)	125(18125)
31.5	11/4”	47(6815)	189(50.19)	47(6815)	47(6815)	120(17400)
40	11/2″	40(5800)	288(76.32)	40(5800)	40(5800)	110(15950)
50	2″	35(5075)	379(100.44)	35(5075)	35(5075)	110(15950)

Female

Part No.	Thread	E	F	G	Part No.	Thread	E	F	G
		(mm.)	(mm.)	( mm.)			(in.）	(in.）	(in.）
QKEP03-03SF	G3/8	65.8	30	41.8	QKEP03-N03SF	NPT3/8	2.59	1.18	1.65
QKEP03-04SF	G1/2	70.8	30	41.8	QKEP03-N04SF	NPT1/2	2.79	1.18	1.65
QKEP04-04SF	G1/2	77.8	36	49.8	QKEP04-N04SF	NPT1/2	3.06	1.42	1.96
QKEP04-06SF	G3/4	84.8	36	49.8	QKEP04-N06SF	NPT3/4	3.34	1.42	1.96
QKEP06-06SF	G3/4	84.8	41	53.8	QKEP06-N06SF	NPT3/4	3.34	1.61	2.12
QKEP06-08SF	G1	97.7	46	58.8	QKEP06-N08SF	NPT1	3.85	1.81	2.31
QKEP08-08SF	G1	99.7	46	58.8	QKEP08-N08SF	NPT1	3.93	1.81	2.31
QKEP08-10SF	G1-1/4	105.8	55	69.8	QKEP08-N10SF	NPT1-1/4	4.17	2.17	2.75
QKEP10-10SF	G1-1/4	106.8	55	69.8	QKEP10-N10SF	NPT1-1/4	4.2	2.17	2.75
QKEP12-10SF	G1-1/4	133.5	65	92	QKEP12-N10SF	NPT1-1/4	5.26	2.56	3.62
QKEP12-12SF	G1-1/2	133.5	65	92	QKEP12-N12SF	NPT1-1/2	5.26	2.56	3.62
QKEP16-16SF	G2	224.8	90	200	QKEP16-N16SF	NPT2	8.85	3.54	7.87

Male

Part No.	Thread	E	F	G	Part No.	Thread	E	F	G
		(mm.)	(mm.)	( mm.)			(in.）	(in.）	(in.）
QKEP03-03PF	G3/8	82.5	27	M33x2	QKEP03-N03PF	NPT3/8	3.25	1.06	M33x2
QKEP03-04PF	G1/2	85	27	M33×2	QKEP03-N04PF	NPT1/2	3.35	1.06	M33×2
QKEP04-04PF	G1/2	95	36	M40×3	QKEP04-NO4PF	NPT1/2	3.74	1.42	M40x3
QKEP04-06PF	G3/4	97.4	36	M40x3	QKEP04-N06PF	NPT3/4	3.83	1.42	M40x3
QKEP06-06PF	G3/4	99	36	M45x3	QKEP06-N06PF	NPT3/4	3.90	1.42	M45x3
QKEP06-08PF	G1	113.6	46	M50x3	QKEP06-N08PF	NPT1	4.47	1.81	M50x3
QKEP08-08PF	G1	113.6	46	M50x3	QKEP08-N08PF	NPT1	4.47	1.81	M50x3
QKEP08-10PF	G1-1/4	123.4	55	M58x3	QKEP08-N10PF	NPT1-1/4	4.86	2.17	M58x3
QKEP10-10PF	G1-1/4	123.4	55	M58x3	QKEP10-N10PF	NPT1-1/4	4.86	2.17	M58x3
QKEP12-10PF	G1-1/4	150	65	M80x4	QKEP12-N10PF	NPT1-1/4	5.91	2.56	M80×4
QKEP12-12PF	G1-1/2	150	65	M80x4	QKEP12-N12PF	NPT1-1/2	5.91	2.56	M80x4
QKEP16-16PF	G2	218.4	90	M130x6	QKEP16-N16PF	NPT2	8.60	3.54	M130x6

Features

Connexion by screwing together the two parts
Disconnexion by unscrewing the two parts
Shut off by flat face valve
Connectable with male part under residual pressure(35MPa-5075PS1) without using tools
Disconnexion under pressure allowed
No spillage during Connexion and Disconnexion
Interchangeability Stucchi Market

Technical Specifcations

High grade carbon steel
tempered or carbonitrited for
specifc stressed area
Polyurethane and NBR
Backup ring in PTFE
-259C oo +1009C
(-13°F t0 +212°F)
100.000 cycles at 133% of rated
pressure disconnected
1.000,000 cycles at 133% of
rated
pressure connected.
Tested according to 1s0 7241-2
specifications
